Technical data
10 Hz – 800 Hz | Measuring range frequency | |
> 150 mm | Minimum free belt strand | |
< 1% | Digital sampling error | |
± 1 Hz | Display error | |
< 5% | Total error | |
+10 °C ... +50 °C | Operating temperature | |
Plastic (ABS) | Housing material | |
2 lines LCD, 16 characters | Display | |
10 | Available languages | |
≤ 9,99 m | Input limit free strand length | |
≤ 9,999 kg/m | Input limit belt mass | |
Battery (9 V) | Power supply | |
max. 2 years (periodic) | Calibration (recommended) | |
80 x 126 x 37 | Dimensions device (mm) | |
255 x 210 x 60 | Dimensions Case (mm) | |
| ≈m | 0.98 kg | Weight |
Additional information
1 pc. measuring instrument, 1 pc. measurement sensor with cable, 1 pc. plug-in sensor, 1 pc. battery, 1 pc. transport case | Included in delivery |
