Main Dimensions & Performance Data
d | 3 3/16 in | Shaft diameter |
H | 10 3/4 in | Housing height |
B | 16 3/4 in | Length base |
≈m | 88 lbs | Weight |
Dimensions
S2BCH-303-FL | Complete unit float | |
S2BCH-303-HD | Complete unit held | |
PH-6 | Housing designation | |
A | 4 15/16 in | Center height |
C | 6 in | Base width |
D | 2 in | Base height |
Emin | 14 in | Base hole distance 1 min |
Emin | 15 in | Base hole distance 1 max |
F | 4 in | Base hole distance 2 |
s | 2 | # of mounting bolts |
s | 3/4 in | Mounting bolt diameter |
S2BC-303-FL | Cartridge float bearing | |
S2BC-303-HD | Cartridge held bearing | |
S2C-308 | Cartridge | |
G | 5 3/4 in | Length through bore |
L | 8 in | Outside diameter cartridge |
1.1 lbs | Grease capacity | |
41.3 lbs | Cartridge weight | |
S2B-303-FL | Bearing float | |
S2B-303-HD | Bearing held | |
17.6 lbs | Bearing weight | |
308 Grp | Bearing group | |
Cr | 57,456 lbf | Basic dynamic load rating, radial |
C0r | 79,616 lbf | Basic static load rating, radial |
Ca | 666 lbf | Basic dynamic load rating, axial |
2,550 1/min | Limiting speed | |
D0 | 6 11/16 in | Outside diameter bearing |
C0 | 3 1/2 in | Width inner ring |
B0 | 1 7/8 in | Width outer ring |
